Refer to the table below for guidance after you've completed the initial steps in the Create a translator procedure above.

Refer to the table below for guidance after you've completed the initial steps in the Create a translator procedure above.

Error translators enable you to translate error messages from one format to another. You can use them as custom error handlers in any component that supports error handling.

Like message translators, error translators accept the document of the envelope being processed (the message payload) and the message headers. The output from the translator is the result of the translation script.

Error information is stored in message headers before passing the headers to the error translator. The headers include the following:

Error Translator Document - The document sent to the error translator is either the document being processed at the time of the error, or (in the case of an HTTP error) the error response body. If the error response body is set as the document, then the original document is stored in the message headers as `original_document`.

Error Translator Output - The output from an error translator is the result of the translation script. The document is returned and flow execution stops. If the flow was initiated as part of a request/response flow, such as an HTTP request, the translated document is returned as the response to the request.

Refer to the table below for guidance after you've completed the initial steps in the Create a translator procedure above.

Groovy map syntax

It's a best practice to use maps for document messages in X1.

In Groovy, a map is defined using the following syntax:

def document = [
  id: '1',
  name: 'foobar',
  items: [
    [id: '1', name: 'item1'],
    [id: '2', name: 'item2']
  ]
]

In this example, a document is defined as a map with an id, name, and items key. The items key is a list of maps, each with an id and name key.

To access a value in a map, use the following syntax:

def id = document.id

To assign a value to a key in a map, use the following syntax:

document.age = 30

Script input

To quickly review, message translator scripts translate a source document into a target document.

The source document passed to the translator can be of any type, but 99% of the time in X1 it'll be a map. The header of the envelope that enclosed the document as well as the Camel message headers are variables available for the script context.

Script output

Groovy translator scripts must output a new document. In Groovy, this can be achieved with a return statement placed at the end of the script.

// script code

return [
	shipmentId: document.id,
	number: document.poNumber
]

Summary

Envelope headers are available for the document translation scripts of translators in the `header` variable.

To test a translator script that uses envelope headers, you can create a test document that's a JSON representation of an X1 envelope that consists of `header` and `document` properties, such as the following example:

```json
{
    "header": {
        "header1": "value1",
        "header2": "value2"
    },
    "document": {
        "field1": "value1",
        "field2": "value2"
    }
}
```

In Groovy, you can declare top-level variables that can be accessed from anywhere in the script. These variables are also known as script-level variables or global variables. Top-level variables are useful when you need to share data across different parts of the script or when you want to create convenience variables that simplify the code.

To declare a top-level variable in a Groovy script, assign a value to a variable without using the def keyword:

shipment = document

In this example, shipment is a top-level variable that refers to document. Now, you can use shipment anywhere in the script to refer to document.

While this dynamic nature provides flexibility, it also means you should be careful when using top-level variables. It's a good practice to use descriptive names for top-level variables and to keep their scope as limited as possible to avoid potential issues with variable name clashes or unexpected type changes.

Groovy provides powerful mechanisms for declaring methods (also called operations or functions) that can be used to encapsulate logic for transforming data. These methods can be called multiple times throughout your script, helping you avoid code repetition and keep your scripts clean and readable.

To declare a method in Groovy, use the def keyword followed by the method name, parentheses for parameters, and then the method body enclosed in curly braces.

Here's an example:

def transformData(data) {
    // Transformation logic goes here
    return transformedData
}

In this example, transformData is a method that takes one parameter, data, and returns transformedData.

These methods are dynamic, meaning they are not bound to a specific type, and can therefore handle data of any type and return any type of result. This dynamic nature allows for great flexibility but also requires that you manage the types of data passed to and returned from these methods.

It's important to note that all method declarations should be placed before the final return statement of the script. This is because Groovy scripts are executed sequentially from top to bottom. If a method is declared after it's called or after the return statement, Groovy won't be able to find the method at runtime, leading to a MissingMethodException.

Here's an example of a script structure with methods:

shipment = document

def transform(shipmentLines) {
    // Transformation logic
    return transformedShipment
}
// Other script code

return transform(shipment.lines)

In this example, the transformData and processData methods are declared at the top of the script, and the actual script logic is below these declarations, ensuring that the methods are defined before they are called.

Introduction to GStrings

A GString, or Groovy String, is an advanced form of a string that can contain expressions that are evaluated and interpolated (embedded) into the string. This feature allows you to construct dynamic strings in a very readable manner.

def name = 'Alice'
def greeting = "Hello, ${name}!" // 'Hello, Alice!'

In this example, ${name} is an expression within the GString. When the GString is evaluated, ${name} is replaced with the value of the name variable.

GStrings can be particularly useful when working with maps. You can embed map values in a GString:

def shipment = [
    id: 12345,
    sender: 'John Doe',
    receiver: 'Jane Smith',
    status: 'In Transit'
]

def message = "Shipment ${shipment.id} is ${shipment.status}"

In this example, the message GString includes the id and status values from the shipment map.

If you need to include a literal ${ in a GString, you can escape it with a backslash:

def amount = 100
def message = "You won \$${amount}"  // 'You won $100'

In this example, the first dollar sign is escaped and therefore is treated as a literal character, not the start of an expression.

GStrings can also be multiline, which can be very useful when you need to construct complex strings:

def shipment = [
    id: 12345,
    sender: 'John Doe',
    receiver: 'Jane Smith',
    status: 'In Transit'
]

def message = """Shipment Details:
ID: ${shipment.id}
Sender: ${shipment.sender}
Receiver: ${shipment.receiver}
Status: ${shipment.status}"""

In this example, the message GString spans multiple lines and includes several values from the shipment map. Each ${} expression is replaced with the corresponding map value when the GString is evaluated.

X1 documents (individual message payloads processed during flow run execution) are maps of data. Translator scripts operate on these maps of data (the document variable) and are expected to output a new map (the translated document).

Declare a map literal

A map literal in Groovy allows storing key-value pairs, providing fast and direct retrieval of values based on unique keys. Declaring a map literal is straightforward, and for better readability, the map can be spread over multiple lines.

Here's an example:

def shipment = [
    id: 12345,
    sender: 'John Doe',
    receiver: 'Jane Smith',
    status: 'In Transit'
]

Access map keys using dot notation

Groovy allows retrieving values in a map by using dot notation. This approach provides a clear and direct way to access a value associated with a key.

Here's how you can do it:

def sender = shipment.sender

Set map values using dot notation

To update or set a value for a key in a map, you can use dot notation.

Here's how you can change a shipment status:

shipment.status = 'Delivered'

Alternative notations for accessing and setting map values using brackets

Groovy provides alternative ways to access and set map values using brackets, which can be handy for dynamic keys or keys containing special characters.

Here's how you can do it:

def receiver = shipment['receiver-code']
shipment['status-code'] = 'Collected'

Merge two maps using << notation

In Groovy, the << operator allows merging two maps. The operator adds all key-value pairs from the second map to the first one. If there are duplicate keys, the values from the second map will overwrite those in the first map.

Here's an example:

def shipment1 = [
    id: 12345,
    sender: 'John Doe',
    receiver: 'Jane Smith',
    status: 'In Transit'
]

def shipment2 = [
    id: 67890,
    sender: 'Alice Johnson',
    receiver: 'Bob Brown',
    status: 'Delivered'
]

shipment1 << shipment2

In the above example, shipment1 will now have the key-value pairs of shipment2.

Safely access map keys that may be null

In Groovy, accessing a key that does not exist in a map will return a null value. However, attempting to call a method or access a property on null will result in a NullPointerException. To prevent this, Groovy provides the safe navigation operator (?.), which returns null instead of throwing an exception when a null value is encountered.

def status = shipment?.status // Returns 'In Transit' if status exists, null otherwise

In the above code, if the shipment map does not have a status key, status will be assigned null instead of causing a NullPointerException. This can be particularly useful when chaining method calls or property access on the result of map key access.

For example, if you want to transform the status value to uppercase, you might be tempted to do something like this:

def status = shipment.status.toUpperCase() // Throws NullPointerException if status does not exist

However, if the status key does not exist in the shipment map, you'll get a NullPointerException.

You can avoid this by using the safe navigation operator:

def status = shipment?.status?.toUpperCase() // Returns null if status does not exist

This code safely calls toUpperCase on shipment.status only if shipment.status is not null. Otherwise, it returns null. This helps in preventing NullPointerException from being thrown in your Groovy scripts and makes them more robust.

Set default values in case of null using the Elvis operator

In Groovy, the Elvis operator (?:) is a handy feature that enables you to specify a default value when the expression on its left-hand side is evaluated to be false or null. This operator is particularly useful when working with map values that may be null, as it allows you to provide a default value.

def status = shipment?.status ?: 'Unknown'

In the above code, if the status key doesn't exist or its value is null in the shipment map, status will be assigned the string 'Unknown'. If the status key exists and its value is not null, status will be assigned that value.

Here's an example of how you could use it to set default values when transforming map values:

def status = (shipment?.status ?: 'Unknown').toUpperCase()

In this case, if the status key doesn't exist or its value is null in the shipment map, 'Unknown' will be used as the default value, and toUpperCase() will be called on 'Unknown'. If the status key exists and its value is not null, toUpperCase() will be called on the actual status value.

The Elvis operator can help in writing more robust Groovy scripts that can handle null and missing values gracefully.

Declare a list

Declaring a list in Groovy is straightforward.

Here's an example of how to declare a list named lineItems:

def lineItems = ['item1', 'item2', 'item3']

Access list elements

You can access elements in a Groovy list using their index, which starts from zero.

Here's how you can retrieve the first item from lineItems:

def firstItem = lineItems[0]

Set list elements

To update the value of a list element using its index, you can do:

lineItems[0] = 'newItem1'

After this operation, the first element of lineItems will be 'newItem1'.

Add elements to a list

You can add elements to a list using the << operator or the add method:

lineItems << 'item4'
lineItems.add('item5')

Remove elements from a list

To remove an element from a list, you can use the remove method with the element's value or index as the parameter:

lineItems.remove('item4')
lineItems.remove(0)

Check list size

To get the number of elements in a list, you can use the size method:

int size = lineItems.size()

Iterate over a list

You can iterate over a list using the each method:

lineItems.each { item ->
    println item
}

Find elements in a list

You can find elements in a list that meet certain conditions using the find method:

def firstItemOverFiveChars = myList.find { it.length() > 5 }

A common use-case in Groovy (and many other languages) is to create a list of maps. This structure is particularly useful for storing complex data, like a list of objects where each object has several properties.

Here's an example where we create a list called shipments, where each shipment is a map with id, sender, receiver, and status keys:

def shipments = [
    [
        id: 12345,
        sender: 'John Doe',
        receiver: 'Jane Smith',
        status: 'In Transit'
    ],
    [
        id: 67890,
        sender: 'Alice Johnson',
        receiver: 'Bob Brown',
        status: 'Delivered'
    ]
]

Access maps in the list

You can access individual shipments in the list using their index:

def firstShipment = shipments[0]  // firstShipment will be the first map in the list

Modify maps in the list

You can modify the properties of individual shipments in the list:

shipments[0].status = 'Delivered'  // The status of the first shipment is now 'Delivered'

Iterate over the list of maps

You can iterate over the list of maps using the each method:

shipments.each { shipment ->
    println "Shipment ID: ${shipment.id}, Status: ${shipment.status}"
}

In this code, each shipment is a map, and you can access its properties using dot notation. This will print the id and status of each shipment in the list.

Collect list elements into a new list of maps

Groovy's collect method is a powerful feature that allows you to transform each element in a list and returns a new list with the transformed elements. This is particularly useful when you want to create a new list of maps based on an existing list.

For example, suppose we have a list of shipments and we want to create a new list containing only the id and status of each shipment.

Here's how you can do it:

def simpleShipments = shipments.collect { shipment ->
    [id: shipment.id, status: shipment.status]
}

In this example, simpleShipments will be a new list of maps. Each map in the list will contain only the id and status of the corresponding shipment in the original shipments list.

The collect method is useful for situations where you want to transform a list of complex objects (like maps or custom classes) into a simpler format for processing or displaying.

Introduction to closures

A closure in Groovy is an open, anonymous, block of code that can take arguments, return a value and be assigned to a variable. A closure may reference variables declared in its surrounding scope. In essence, it’s like a “code block” or a method pointer. It’s defined within curly braces {}.

Use closures with collect

collect is a method that transforms each element in a collection based on the logic defined in a closure and returns a new collection with the transformed elements.

def shipmentLines = [
    ['id': '001', 'quantity': 10, 'price': 5.0],
    ['id': '002', 'quantity': 15, 'price': 3.5],
    ['id': '003', 'quantity': 8, 'price': 7.0]
]

def totalPrices = shipmentLines.collect { line -> line.quantity * line.price }

In this example, the closure { line -> line.quantity * line.price } is applied to each element in the shipmentLines list. The result is a new list where each line is replaced with the total price for that line.

Use closures with each

The each method applies a closure to each item in a collection. This is useful for performing an operation on each item.

def shipmentLines = ['item1', 'item2', 'item3']
shipmentLines.each { line -> println(line) }

In this example, the closure { line -> println(line) } is applied to each element in the shipmentLines list. Each line is printed to the console.

Use closures with find

The find method applies a closure to the items in a collection and returns the first item for which the closure returns true.

def shipmentLines = [
    ['id': '001', 'quantity': 10, 'price': 5.0],
    ['id': '002', 'quantity': 15, 'price': 3.5],
    ['id': '003', 'quantity': 8, 'price': 7.0]
]

def firstExpensiveLine = shipmentLines.find { line -> line.price > 6.0 }

In this example, the closure { line -> line.price > 6.0 } is applied to each element in the shipmentLines list. The find method returns the first line where the price is greater than 6.0.

In Groovy, certain values are considered "falsy" or represent "untruth", while all other values are considered "truthy". This is commonly referred to as Groovy Truth. It's a core concept in Groovy and is widely used in conditional statements, looping, and so on.

The following values are considered "falsy" in Groovy:

Everything else is considered "truthy".

This feature allows you to write clear and concise code when checking for null or empty values.

For example, to check if a shipment has line items, you can write:

if (shipment.lineItems) {
    // Process the line items
}

In this example, if shipment.lineItems is null, an empty collection, or any other "falsy" value, the code inside the if block won't be executed. On the other hand, if shipment.lineItems contains at least one item, the code inside the if block will be executed.

This reduces the need for more verbose null or emptiness checks, such as if (shipment.lineItems != null && !shipment.lineItems.isEmpty()). With Groovy Truth, your code becomes more readable and maintainable.

X1 endpoints can be configured to send and receive XML messages. These endpoints automatically convert the document message to XML.

When writing a translator script that produces a document message that'll be converted to XML, create the schema that the XML document should conform to. The X1 endpoint will automatically convert the document to XML using the schema.

Scripting XML attributes

To create an XML attribute, use the @ symbol in the key of the map.

For example:

def document = [
  person: [
    id: '1',
    name: 'foobar',
    '@age': 30
  ]
]

This produces the following XML:

<person age="30">
  <id>1</id>
  <name>foobar</name>
</person>

Script XML Elements with a single literal value

Some XML elements consist of multiple attributes and a single literal value. To create an XML element with attributes and a single literal value, use the value key in the map alongside the '@' attribute keys.

For example:

def document = [
  person: [
    @id: '1',
    @age: 30,
    value: 'foobar'
  ]
]

This produces the following XML:

<person id="1" age="30">foobar</person>
